Fire Resistant Shaft Door Features

With the knowledge of qualified engineers, Dimak has been able to provide an unmatched quality array of fire resistant shaft doors (access panel) within the assured time period. These fire rated shaft doors are one of the best examples of the finest quality products of Dimak Door and Door Systems. All fire rated shaft doors and door sets are produced by using the latest machinery handled by qualified and experienced staffs, ensuring customers that all products are well manufactured.

• Tested according to EN 1634-1 standards
• Certification for 90 minutes fire rating
• Produced in customer-specific sizes
• The shaft doors are coated with electrostatic powder coating process in our modern robotic coating line.
• The standard color is RAL 9002, however any requested RAL color can be applied.***
• Shaft door frame and shaft door leaf can be coated in different RAL colors.
• Shaft door leaf has 63 mm thickness and produced from 0.80 mm thick galvanized steel.
• Frame is produced from 1.50 mm galvanized steel.
• Galvanized steel is used in the production of door frames and door leaves therefore the doors are highly enduring to corrosion.
• The galvanized steel has a special surface suitable for electrostatic powder coating.
• Due to its unique sectional design, the shaft door frame and leaf are very rigid.
• High-quality thermo expanding (intumescent) seal on the frame.

You can visit our Documents page to view all Dimak Fire Resistant Shaft Door Features.
